  5. LY-05D
560KD05J

560KD05J

560KD05J

MOV

MOV
Specification download
Part Number

Varistor Voltage

V1mA (V)

Maximum Allowable Voltage

VAC (V)

VDC (V)

Maximum Clamping Voltage

IP (A)

VC (V)

Surge Current

I (A)

Maximum Energy (10/1000μs)

E (J)

Maximum Leakage Current @83% o

IR (μA)

Rated Power

P (W)

Typical Capacitance (Reference

@1KHz (pF)

Size(mm)
560KD05J
56(50~62)
35 45
1 123
250
1.8
50
0.01
450
Φ5
